TECNA PROVASET 2P - PROVASET 2 P Technical Specifications; Key Technical Specifications Overview

UNITS OF
MEASURE
2P2B00
RANGE
2P6B00
RANGE
mmH
2
O
510 ÷ 20394 1020 ÷ 61182
mbar
50.0 ÷ 2000.0 100.0 ÷ 6000.0
kPa
5.00 ÷ 200.00 10.00 ÷ 600.00
mmHg
37.5 ÷ 1500.0 75.0 ÷ 4500.0
PSI
0.75 ÷ 30.00 1.50 ÷ 90.00
inH
2
O
20.1 ÷ 802.5 40.2 ÷ 2407.5
PROVASET 2P code 2P2B00 - 2P6B00 - Instruction manual
rev. 14/02/2013
page 30
9 TECHNICAL FEATURES
Power supply Universal 115 ÷ 230Vac, 50÷ 60 Hz
Current 35VA
Compressed air line 10 bar max, filtered air, connector for tube 6x4 mm
Fuses 2 fuses T 630 mA 5 x 20 mm
Operating ambient Temperature 5 ÷ 50 °C
Relative humidity max. 80% HR
Sensor calibration software procedure with keyboard
A/D converter 16 bits - 20 readings per second
MIN and MAX.
test pressure:
Tolerance adjustment
of the test pressure : +/- 40 mbar, 2 bar range;
+/- 60 mbar, 6 bar range.
Resolution 1 mmH
2
O
Class 0.5 % FS
Keyboard touch-activated (software protection against accidental
parameter changes)
5 keys for parameters programming
Manual Start button
Display back-lit graphic LCD 128x64
green led, red led
Test tables 16 tables of programmable parameters
Test counter PASSED and FAILED counters, with manual zero reset
Sound alarm built-in buzzer, programmable time
Connections to the PLC 1 photo-coupled p.n.p. input:
- START : test start
3 photo-coupled p.n.p. outputs:
-PASSED, FAILED TEST IN PROGRESS
Case stainless steel
Protection degree IP40
Size mm 160 x 135 x 180 (WxHxL )
Weight Kg 3.300
