PROVASET T3LPF REV.20210610
18
1: + +24V= 2: – -0V common
3: <1 (Output 1) 4: 1< (Input 1)
5: <2 (Output 2) 6: 2< (Input 2)
7: <3 (Output 3) 8: 3< (Input 3)
9: <4 (Output 4) 10: 4< (Input 4)
11: + (Output +) 12: 5< (Input 5)
13: + (Output +) 14: 6< (Input 6)
15: <5 (Output 5) 16: 7< (Input 7)
17: <6 (Output 6) 18: 8< (Input 8)
19: <7 (Output 7) 20: – (Output -)
21: <8 (Output 8) 22: – (Output -)
23: +Vx (Output +Vx) 24: – (Output -Vx)
Power supply for digital inputs/outputs:
+ external power supply of PLC: +24V=
- external power supply of PLC: -0V common
Digital I/O
Output <1: <8
Output + Auxiliary output at positive power supply voltage +
Output - Auxiliary output at power supply common 0 Volt -
Input 1<: 8<
If an external power supply is not available (+ PLC 24V=), it is possible to use the inter-
nal power supply (+Vx , -Vx ) of the equipment; connections:
23: +Vx (Output +Vx) connected to 1: + (PLC: +24V=
24: -Vx (Output -Vx) connected to 2: - (PLC: -0V common)
The maximum output current is limited to 300 mA (max 10W), protected by an autore-
settable internal fuse.
The digital outputs and inputs are isolated, up to 50 Volts, if supplied by an external
power supply (24V=PLC). The digital inputs and outputs are not isolated if powered by
the internal power supply +VX and -VX.
