PROVASET T3LPF REV.20210610
4
SUMMARY
1. LIST OF USED SYMBOLS pag.8
2. RISKS AND WARNINGS pag.9
3. GENERAL INFORMATION pag.10
3.1 Description pag.10
3.1.1 Available options pag.11
3.1.2 Available accessories pag.11
3.2 Packaging and transport pag.11
3.3 Storage pag.11
3.4 Front panel pag.12
3.5 Rear panel with mains power supply (90 ÷ 230 Vac) pag.13
3.5.1 Rear panel for external 24 Vdc power supply pag.14
3.6 Fuses pag.15
3.7 Manufacturer label pag.16
3.8 Expansion board pag.17
3.8.1 Expansion board, 8 inputs / 8 outputs (type IOB) pag.17
3.9 Lights tower indicator, loud alarm, remote control box pag.20
3.10 PLC: interface signals pag.21
3.11 Pneumatic diagram pag.22
3.12 Pneumatic installation, air supply and test connections pag.24
3.12.1 Flow rate test: connection with remote pressure reading pag.25
3.12.2 Flow rate test: connection with local pressure reading pag.28
3.12.3 Leak test: pneumatic connections pag.29
pag.29
4. MAIN MENU pag.30
5. USER INFORMATION pag.31
5.1 Power on pag.31
5.2 Touch screen keys for managing display menus pag.32
5.3 Information pages display pag.33
5.4 Testing products and programs pag.34
5.4.1 Products pag.35
5.4.1.1 Product parameters pag.35
5.4.2 Test programs pag.37
