PROVASET T3LPF REV.20210610
97
Case
Materials
Anodized aluminium
ABS
Size 255 x 181 x 286 mm
Weight 7.0 Kg
Auxiliary power supply output +Vx
24 Vcc, 300 mA max
Resettable fuse, not isolated output
Serial line USB 2.0 USB type B connector, 5 Vcc; isolation, 50V max
Serial line RS232/RS485
5 Vcc for RS485 signals
+/-12 Vcc for RS232 signals; isolation, 50V max
PLC digital inputs
24Vcc, 3 mA max
Conforming to IEC 61131-2; isolation, 50V max
PLC digital outputs
24Vcc, 0.7 A max
Conforming to IEC 61131-2; isolation, 50V max
the nl/min scale is set at 1013 mbar and 0°C; the instrument can be cali-
14.2 Size, weight, brackets
286
181
255
Weight: 7.0 kg ( basic weight without accessories and options).
equipment to the test bench; the brackets are mounted on the rear screws of the
cover plates.
