Section 7 – Airframe and Systems description
Flight Controls
STABILIZER
TAB
Fig. 7-3. P92 Echo MkII stabilator and tab
Fig. 7-4. P92 Echo MkII vertical tail and fin
3. FLIGHT CONTROLS
The primary flight controls are of conventional type, operated by control stick and
rudder pedals. Stabilator, as per Figure 7-4, is actuated by push-pull rods and ca-
bles.
