October ‘ 98
7-4
COSTRUZIONI AERONAUTICHE
TECNAM S.r.l.
P96 Golf
P96 Golf / 100
SYSTEMS
FLIGHT MANUAL
SEATS AND SAFETY HARNESS
Aircraft features four point fitting safety belts with waist and diagonal straps
adjustable via a sliding metal buckle.
Seats are built with light alloy tube structure and synthetic material cushioning. A
lever located on the right lower side of each seat allows adjustment of seat position
according to pilot size.
SLIDING CANOPY
The cabin's canopy slides on wheel bearings along tracks located on fuselage sides;
canopy is made out of composite material. Latching system uses a central lever located
overhead and two additional levers positioned on canopy's sides.
ENGINE
P96 Golf
ROTAX 912UL, 4 stroke, horizontally-opposed 4 cylinder, mixed air and water
cooled, twin electronic ignition, forced lubrication
Maximum rating - 81Hp (59.6 Kw) at 5800 RPM
Reduction gearbox - 2.273:1
Prop GT-ECHO 2/166/145
P96 Golf/100
ROTAX 912S, 4 stroke, horizontally-opposed 4 cylinder, mixed air and water
cooled, twin electronic ignition, forced lubrication
Maximum rating - 100 Hp (73.5 Kw) a 5800 g/min
Reduction gearbox - 2.4286:1
Prop GT-ECHO 2/172/164
For further information refer to “Engine Operating Manual”.
FUEL SYSTEM
The system consists of two 35 liter aluminium fuel tanks that are integral part of
the leading edge. Each tank is equipped with cabin installed shut-off valve and of
a main filter located on the firewall and equipped with a drainage valve.
Fuel level is monitored via two analogic displays located on dashboard. Fuel feed
is via an engine driven fuel pump and an emergency electric fuel pump which
can
