This document is a user manual for the TECNO TH300 Intelligent Security WiFi Camera.

Function Description

The TECNO TH300 is an intelligent security WiFi camera designed for surveillance and monitoring. It can be placed on flat surfaces like desks or tables, or mounted on walls. The camera connects to the "TECNO Smart Home" APP, allowing for control and interconnection with other smart home products. It features a MicroSD card slot for local storage and an indicator light to show its status.

Important Technical Specifications

Model: TH300
Product Name: Intelligent Security WiFi Camera
Product Size: 121.8mm x 77mm x 77mm
Product Net Weight: 219g
Power Input: 5V-1A
Resolution: 2K
Aperture: F2.0
Operating Temperature: -10°C to 50°C
Video Encoding: H.265
Wireless Connection: Wi-Fi IEEE 802.11b/b/n 2.4GHz
PTZ Rotation: Vertical 170°
Storage Function: MicroSD card (Maximum capacity supports 128GB)
Support System: Android 4.4 or iOS 9.0 and above

Usage Features

Package List: The manual instructs users to check the camera host and accessories upon opening the package. Components: The camera features an indicator light, lens, microphone, MicroSD card slot, speaker, reset button, and a Type-C port for power. Installation: * Flat Surface Placement: Can be placed on writing desks, dining tables, coffee tables, etc. * Hanging Wall Installation: 1. Mark the wall using the base hole as a guide. 2. Drill two holes (approx. 6mm diameter, 30mm depth). 3. Screw plastic expansion nuts into the holes. 4. Align the base (arrow side up) with the wall holes, insert screws through the base, and secure into the expansion nuts with a cross screwdriver. 5. Align the notch on the camera's bottom with the raised portion of the base, snap it into place, and rotate clockwise to lock. Installing a MicroSD Card: * Ensure the camera is powered off. * Toggle the lens up to expose the MicroSD card slot. * Insert the MicroSD card with the contact side facing down. * Note: The camera must be powered off for installation/removal. Use a MicroSD card from a regular manufacturer (max 128GB), with a read/write speed of at least U1/Class10 level. Power On: * Plug the power cable into the Type-C port on the back of the camera. * The camera will automatically turn on, indicated by a flashing green light. * Tip: Do not force the lens to rotate manually after powering on. If the lens positioning is inaccurate, it can be calibrated via the APP. Indicator Light Status: * Green light always on: Successful connection/normal status. * Green light flashing: Waiting for connection. * Green light slow flashing: Upgrading. * Red light flashing: Network abnormal. Connecting to "TECNO Smart Home" APP: * The camera is controlled by the "TECNO Smart Home" APP and can interconnect with other products. * Users can scan a QR code to download and install the APP, which will direct them to the device connection page if already installed. * Alternatively, search for "TECNO Smart Home" in the app store. * Open the APP, click "+" in the top right corner, and follow the APP instructions to add devices. Register and Log In to APP: * Users need to register an APP account and log in, or log in directly if already registered.

Maintenance Features

Attentions (Important Usage Guidelines):

Temperature: Suitable for -10°C to 50°C. Avoid using in environments with excessively high or low temperatures.
Humidity/Water: This is a precision electronic product. Avoid excessively humid environments or exposure to water to prevent damage.
Lens Placement: To optimize performance, avoid placing the camera near glass, white walls, or other reflective objects that could cause bright near and dark far or white phenomena in images.
Wi-Fi Signal: Ensure the product is installed within the Wi-Fi signal coverage area and placed in a location with good Wi-Fi signal. Try to avoid installation near metal objects and microwave ovens, which can interfere with the signal. Warranty:
A limited 1-year warranty applies to the TECNO TH300 purchased from the Tecno-Mobile-Official store.
The warranty covers original TECNO products and does not apply to normal wear and tear, or damage caused by misuse.
The warranty is for primary products only; additional or free products are not covered.
Contact information for service is provided: service.us@tecno-mobil0.com and www.tecno-mobile.com.
The product is marked "MADE IN CHINA" and includes a RoHS compliance symbol.

Tecno TH300 - Customer Service; Warranty Certificate
