TECNOEKA EKF 412 - Oven Door Cleaning; Oven Lamp Replacement

Electric Ovens rev. 1_____________________________________ EKF 412 – EKF 412 U - EKF 412 AL – EKF 412 ALU
_________________________________________________________________________________________ page 11
Cleaning flap door (for pre-set ovens)
For more comprehensive oven door cleaning it is recommended to proceed as follows:
- open the door completely;
- insert the suitable pins supplied in the holes “A” on the two hinges (Fig. 8);
- slightly lift the door and extract it (Fig. 9);
Replace the door in its housing operating in reverse order.
(Fig. 3) (Fig. 4)
Replacing oven lamp - Electrically switch off the appliance; unscrew the protective glass cap;
unscrew the screws that secure the glass support and the relative seal (Fig.5) and replace it with
another lamp suitable for high temperatures (300°C), with the following characteristics:
- Voltage 230/240 V
- Power 40 W
The lamp is of the halogen type: it must not be touched with bare hands.
Reassemble the glass support and its gasket.
(Fig.5)
A
