COVER REGULATION
WHEEL
COVER
20825 BARLASSINA (MI) - via Machiavelli, 16
www.tecnoinoxsrl.it - info@tecnoinoxsrl.it
ASSEMBLY INSTRUCTIONS P-ONE
STEP 11
- Verify the closure of the drawer: in the case it doesn't close
(probably due to a friction between bins and cover) rotate the
front screw to regulate the stop position of the cover.
STEP 10
- Insert bins.
STEP 9
- Fix rails using screws fixed before in front panel and using n°2 viti M4x16 TC/CR to fix them to the back
steel components.
