DMX-512 Connections
The DMX-512 is widely used in intelligent lighting control
with a maximum of 512 channels.
Temperature reduces signal error and avoids signal trans-
mission problems and interference. It is always advisable to
connect a DMX terminal. (Resistance 120 ohm 1/4W) between
pin2 (DMX-) and pin3 (DMX+) of the last xture
4CH Channel mode
p. 7NEBULA 1 - 36x1 W LED PAR LIGHT
English Version
