Tecson Hotec H-U25 - Product Specifications; System Specifications

6
Note:
The computer recognizes the microphone automatically after the receiver is connected
correctly as shown above. If not, go to Control Panel/Sound/Recording, click the external
microphone and go to Configuration. If you need any assistance in setting up, please contact
Hotec customer service.
Product Specification
SYSTEM SPECIFICATIONS
Modulation mode
Digital Frequency Modulate
Frequency Range
UHF 500
-
980MHz
Preset Frequencies
25 (auto pairing)
Frequency Response
75Hz ~ 18kHz +/
-
3dB
Max.
Deviation Range
+/
-
50kHz (with level limiting)
T.H.D
<1.0% @1kHz
S/N
>98dB
Working Range
Up to 100 feet
RF Carrier Stability
+/
-
0.005% (14
℉
-
122
℉
)
Figure 5
Figure 6
