9
T-154 0-240°C protection relays
TECSYSTEM S.r.l ®
18) PROGRAMMING REHABILITATION IN CASE OF BLOCK (Prg no)
In the event program access is blocked the display will show SET and then display “noP”.
To gain access, press the ENT key and return to normal operation. Touch the PRG key
and then, press and hold the TEST key for approximately 7 seconds until the flashing
PRG screen display ends, and the message nCH is displayed.
NOTE: this procedure removes the lockout feature. To block access again, this feature
must be reprogrammed.
19) WARRANTY
The “T” series units are warranted for a period of 12 months from the delivery date
marked on the unit.
Warranty is limited to repair or replacement of the defective products and no contingent
liabilities will be accepted.
Warranty will be voided if the unit is found to be tampered with or when it has been dam-
aged as a result of incorrect input or power supply connections (out of the max working
limits 20+270 Vac-dc). Warranty will be voided if the unit is damaged as a result of transi-
tory overvoltages. Freight expense is not covered under warranty.
In case of dispute, the qualified FORUM is the one in Milan.
20) PT100 EXTENSION CABLE: TECHNICAL SPECIFICATIONS
Cable 20xAWG 20/19 cu/stg
Section 0.55 mm²
Antiflame Insulation PVC105
In accordance with CEI 20.35 IEC 332.1
Max. working temperature: 105°C
Conformation : 4 terns of the numbered conductors (1-1-1.........4-4-4)
RRW twisted and coloured conductors
Shield cu/stg
PVC Antiflame protecting covering
External diameter 9.0 mm
Skeins of 100 m
