MODEL XQ140/20 HYDRAULIC POWER TONG OPERATION MANUAL
YANCHENG TEDA DRILLING & PRODUCTION EQUIPMENT CO.,LTD
Table 10.4 Tong head assembly parts list
NO.
P/N
Parts number
Description
Qty.
1
XQ20-65
GB/T70
Hexagon socket head cap screw
M10
×
40
17
2
XQ20-66
XQ20.1.1-1
Open gear cover
1
3
XQ20-67
XQ20.1.1-2
Jaw plate frame
1
4
XQ20-68
XYQ12.B-10
Position screw
2
5
XQ20-69
XQ20.1.1-3
Open gear
1
6
XQ20-70
GB/T70
Hexagon socket head cap screw
M10×20
12
7
XQ20-71(1)
XYQ12.Z-01.12 (1A-3A)
Die (1)
4
XQ20-71(2)
Die (2)
4
XQ20-71(3)
Die (3)
4
8
XQ20-72(1)
XQ20.1.1-8(1-9)
Die seat(1)
2
XQ20-72(2)
Die seat (2)
2
XQ20-72(3)
Die seat (3)
2
XQ20-72(4)
Die seat (4)
2
XQ20-72(5)
Die seat (5)
2
XQ20-72(6)
Die seat (6)
2
XQ20-72(7)
Die seat (7)
2
XQ20-72(8)
Die seat (8)
2
XQ20-72(9)
Die seat (9)
2
9
XQ20-73
XYQ12.Z-01.11
Screw stop pin
8
10
XQ20-74
XQ20.1.1-6
Roller shaft
2
11
XQ20-75
GB/T71
Slotted cone pointed set screw
M8×12
4
12
XQ20-76
XQ20.1.1-4
Roller
2
13
XQ20-77
XQ20.1.1-7
Jaw plate
2
14
XQ20-78
XYQ12.Z-01.13
Pin
4
15
XQ20-79
XQ20.1.1-5
Ramp
4
