MODEL XQ140/20 HYDRAULIC POWER TONG OPERATION MANUAL
YANCHENG TEDA DRILLING & PRODUCTION EQUIPMENT CO.,LTD
10
XQ20-214
XQ20.2-2
Backup tong jaw plate frame
1
11
XQ20-215
XYQ12.B-10
Location screw
2
12
XQ20-216
XQ20.2-6
Ramp
4
13
XQ20-217
XQ20.2-5
Front support seat
2
14
XQ20-218
GB/T93
Standard spring washer 12
4
15
XQ20-219
GB/T70.1
Hexagon socket head cap screw
M12
×
25
4
16
XQ20-220
GB/T95
Hexagon nut M12
3
17
XQ20-221
GB/T95
Flat washer 12
1
18
XQ20-222
GB/T70.1
Hexagon socket head cap screw
M10
×
25
27
19
XQ20-223
GB/T93
Standard spring washer 10
27
20
XQ20-224
XQ20.2-14
Shaft
1
21
XQ20-225
XYQ12.B-35
Roller
1
22
XQ20-71(1)
XYQ12.Z-01.12
(1A-3A)
Die(1)
4
XQ20-71(2)
Die(2)
4
XQ20-71(3)
Die(3)
4
23
XQ20-72(1)
XQ20.1.1-8(1-9)
Die seat (1)
2
XQ20-72(2)
Die seat (2)
2
XQ20-72(3)
Die seat (3)
2
XQ20-72(4)
Die seat (4)
2
XQ20-72(5)
Die seat (5)
2
XQ20-72(6)
Die seat (6)
2
XQ20-72(7)
Die seat (7)
2
XQ20-72(8)
Die seat (8)
2
XQ20-72(9)
Die seat (9)
2
XQ20-226
XQ20.2-8
Die seat (156)
2
24
XQ20-73
XYQ12.Z-01.11
Stop pin
8
25
XQ20-74
XQ20.1.1-6
Roller shaft
2
26
XQ20-75
GB/T71
Slotted cone point fastening screw
M8
×
12
4
27
XQ20-76
XQ20.1.1-4
Roller
2
28
XQ20-227
XQ20.2-7
Backup tong jaw plate f
2
29
XQ20-78
XYQ12.Z-01.13
Pin
4
30
XQ20-228
XQ20.2-3
Backup tong body
1
