MODEL XQ140/20 HYDRAULIC POWER TONG OPERATION MANUAL
YANCHENG TEDA DRILLING & PRODUCTION EQUIPMENT CO.,LTD
Table10.6 Transmission parts list
NO.
P/N
Parts number
Description
Qty.
1
XQ20-114
XQ20.1-35
Location plate
2
2
XQ20-115
GB/T1152
Oil cup M10
×
1
5
3
XQ20-116
XQ20.1-34
Idle gear shaft
2
4
XQ20-117
XQ20.1-33
Bushing
2
5
XQ20-118
XQ20.1-32
Waterproof cover
2
6
XQ20-119
GB/T3452.1
O ring 45×3.55
2
7
XQ20-120
GB/T893.1
Circlip for hole 100
4
8
XQ20-121
XQ20.1-37
Idle gear
2
9
XQ20-122
GB/T283
Cylindrical roller bearing NJ309E
2
10
XQ20-123
XQ20.1-36
Spacer ring (2)
2
11
XQ20-124
GB/T283
Cylindrical roller bearing NJ2309E
2
12
XQ20-125
XQ20.1-31
Support plate
2
13
XQ20-126
XQ20.1-19
Support ring (lower)
2
14
XQ20-127
GB/T308
Steel ball
Ø
6
66
15
XQ20-128
XQ20.1-17
Duplex gear (lower)
1
16
XQ20-129
Cylindrical roller 10×30
79
17
XQ20-130
XQ20.1-20
Spacer ring (1)
2
18
XQ20-131
XQ20.1-18
Central spindle (lower)
1
19
XQ20-132
XYQ12.Z-28
Central spindle (upper)
1
20
XQ20-133
XQ20.1-27
Support ring (upper)
2
21
XQ20-134
XQ20.1-28
Spacer ring (upper)
1
22
XQ20-135
XQ20.1-29
Duplex gear (upper))
1
23
XQ20-47
XQ20.1-25
Cabinet
1
24
XQ20-136
XYQ12.Z-23
Washer
1
25
XQ20-137
GB/T276
Ball bearing 6011-2RZ
1
26
XQ20-138
XYQ12.Z-26
Spline gear shaft
1
27
XQ20-139
XYQ12.Z-25
Inner spline gear (1)
1
28
XQ20-140
GB/T276
Ball bearing 6208-2RZ
1
29
XQ20-141
XQ20.1-26
Spindle gear
1
30
XQ20-142
GB/T276
Ball bearing 6217-2RZ
1
31
XQ20-143
GB/T894
Circlip for shaft 80
1
32
XQ20-23
XQ20.1-1
Shell
1
33
XQ20-144
GB/T895.2
Steel stop ring 60
1
34
XQ20-145
GB/T309
Needle roller Φ4×25.8
50
35
XQ20-146
XYQ12.Z-11
Shift gear
1
36
XQ20-147
XYQ12.Z-16
Spindle gear
1
