C
Install strike on the door frame.
D
Change Handle Direction (Optional)
Make sure the hole in door frame is
drilled a minimum of 1" (25mm) deep.
IMPORTANT:
5
Change the Handle direction of exterior assembly. Change the Handle direction of interior assembly.
Loosen the screw completely and remove the screw by using a
screwdriver. Rotate the handle to the other side and keep the handle
horizontal. Tighten the screw in the Left-hand or Right-hand screw holes
according to the actual handle direction.
Loosen the reversing screw by using a screwdriver. Rotate
the lever to the other end and keep it horizontal. Tighten the
reversing screw.
2
The handle direction can be changed for compatible with both right handed and left handed doors.
Notes:
Strike Screws (I)
D
1
To Next Page
