Wall Fittin
Some models are prepared for wall fitting. See below.
A Max. Load:
FS60CP 345 20 kgs.
FS80CP 360 30 kgs.
FSC100 527 30 kgs.
Drill 2 holes with a diameter of 8 mm and a depth of 40 mm and
a distance as shown on the drawing (A).
Insert 8 mm plugs.
Use 4.8 x 38 mm screws, DIN NO.7981.
Make sure the distance between the screw head and the wall is
2-3 mm.
Make sure the screws fit perfectly into the wall fitting.
