Description of the oven
1
Control panel
2
Door lock (only for
pyrolytic models)
3
Grill element
4
Tray supports
(depending on the model)
5
Grid shelf
6
Tray
7
Hinge
8
Inner Glass
9
Air cooling outlet
10
Unit mounting
11
Lamp
12
Back Wall Panel
13
Fan
14
OvenSeal
15
Door
Control panel
HSB, HBB, HCB Models
HSB E Models
1
10
12
13
14
15
5
6
7
8
3
2
4
9
11
3
Temperature control dial.
4
Control knobs for the hob.
1
Function control dial.
2
Electric clock/timer.
5
Cooker indicator light. It indicates
that one or more of the electric
hotplates are on.
1
Function control dial.
2
Electric clock/timer / Selected temperature.
3
Temperature control dial.
5 24 414 43
1 2 3
min
MAX
1 2 3
HSB P, HCB P Pyrolytic models
