9
4)Install the hinge shaft and shaft sleeve to the left hole of the lower hinge, and then the lower hinge
to the left corner of the refrigerator, then adjusting foot A according to the position shown in the
Figure, and finally the adjusting foot B to the right lower corner of the refrigerator.
After completing the assembly
.
Sleeve
Adjusting foot foot A
Adjusting foot foot B
Lower hinge
Adjusting foot foot A
Adjusting foot foot B
