362 View Menu (1 of 1)
Current outdoor air temperature as measured by the outdoor
sensor. This is also the default display for the control.
-67 to 149˚F
(-55 to 65˚C)
• • • •
Target room air temperature. “– – –” denotes no heat is
required.
10K = INDR MODE = —1—
- - -, 35 to 100˚F
(2 to 38˚C)
• • •
Section
LTD
INST
ADV
Range
Access
Level
DescriptionItem Field
USER
Measured room air temperature at the indoor sensor.
10K = INDR MODE = —1—
-58 to 167˚F
(-50 to 75˚C)
This is the signal that is being received from a tekmar Zone
Control.
10K = ZoIn MODE = —1—
- - -, 35 to 110˚F
(2 to 43˚C)
•
• • • •
Slab sensor target temperature. This is the temperature
that the control is trying to maintain at the slab sensor.
10K = SLAB MODE = —2—
- - -, -58° to 167˚F
(-50 to 75˚C)
•
Current slab sensor temperature.
10K = SLAB
MIX MIN = OFF
-58 to 167˚F
(-50 to 75˚C)
STRT, STOP, IDLE, EXT,
0:00 to 17:00 hr, - - -,
INF, WWSD, CWCO
• •
Target mixed supply is the temperature the control is
currently trying to maintain at the mixing sensor.
- - -, -25 to 248˚F
(-32 to 120˚C)
• •
Current mixed supply water temperature as measured by
the mixing sensor.
-31 to 266˚F
(-35 to 130˚C)
• • •
• • • •
Current operating status of the snow melting system.
MODE = —2—
Target boiler supply is the temperature the control is currently
trying to maintain at the boiler sensor +/- 1/2 of the
differential.
BOIL SENS = SUP MODE = —1—
- - -, -31 to 266˚F
(-35 to 130˚C)
• •
Current boiler supply water temperature as measured by
the boiler sensor.
BOIL SENS = SUP
-31 to 266˚F
(-35 to 130˚C)
• • •
• •
Current mixed ∆T difference between the mixed supply
sensor and the mixed return sensor.
∆T MAX ≠ OFF
Boil SENS ≠ SUP MODE = —2—
-85 to 170˚F
(-65 to 77˚C)
Current boiler return water temperature as measured by
the boiler sensor.
BOIL SENS = RET
-31 to 266˚F
(-35 to 130˚C)
• • •
B2
B2
B2
C3
B2
C1
B1
A
B1
C1
C1
D1
D1
D2
