© 2016 tekmar 665
_
D - 06/16
27 of 28
Sensor Technical Data
Outdoor Sensor 070
Literature 070_D, 070_C
Packaged weight 0.17 lb. (77 g)
Dimensions 2-5/8" H x 1-9/16" W x 1-11/16" D (67 x 40 x 43 mm)
Enclosure
White PVC plastic, NEMA type 2
Operating range -60 to 140°F (-51 to 60°C)
Sensor NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892
Warranty Limited 3 Year (See D070 for full warranty)
Notes
