Teknatool Nova Voyager DVR - Parts list - pillar drill

34 Original user manual
28 | Parts list - pillar drill
Pos.
Partnumber
Description
Pos.
Partnumber
Description
01
C05016
Cylinder screw M5x16
48
8339026
Control panel
02
8330355
Upper cover
49
8338021
Emergency stop switch
03
C08040
Cap screw M8
50
C05020
Cheese head screw
Socket head M5x20
04
55431
Location pin
05
52003
Fan encoder
51
8338023
Depth sensor cover
06
8330354
Bearing housing fan sensor
52
8339021
Depth sensor
07
8338002
Wave spring washer
53
8339044
Insert block
08
6005ZZ
Ball bearing
54
8339043
Depth sensor gear
09
55430
Location pin (stator)
55
598123011
LCD Screen
10
55009
DVR stator
55400
HMI
11
55007
DVR rotor
56
8339028
HMI encoder
12
8339016
DVR motor spindle
57
8338024
USB-B port
13
55050
DVR motor spindle key
58
8339014
Front panel
59
8339032
Adjustment wheel
14
8339017
DVR motor spindle
Serrated washers
60
8338025
Plinth
61
8338026
Hexagon screw
M12-1.75x30
15
6005ZZ
Ball bearing
16
8338003
Spindle 152.4 mm
62
8338027
Column holder
17
6203LLB
Ball bearing
63
8338028
Column
18
8338004
Chuck arbour
64
8338029
Gear rack
19
8339012
Quill
65
8338030
Rack ring
20
8330353
Headstock housing
66
SZ1010
Safety screw M10x10
21
8338005
Spring nut
67
8338032
Clamping lever
22
8338006
Spring cover
68
8338033
Table arm bracket
23
8338007
Return spring
69
8338034
Gear
24
8338008
Pinion shaft
70
8338035
Worm gear
25
8338009
Quill driving handle
71
8338036
Winding handle
26
C0408
Cheese head screw
Socket head M4x8
72
8338037
Handle
73
8338038
Gear shaft
27
6205LLB
Ball bearing
74
SZ0810
Safety screw M8x10
28
8339041
Depth stop mount
75
8338040
Table arm
29
C06020
Cylinder screw M6x20
76
8338041
Clamping lever
30
CM5010180
Flat-head screw
77
8338042
Washer 3/4”
31
8338010
Quill lock bolt
78
SZ06010
Safety screw M6x10
32
C06030
Cylinder screw M6x30
79
BNMZ20040
Hexagon screw M20 x 40
33
8338011
Clamping lever
Quill lock
80
SZ1030
Safety screw M10x30
81
8338046
Work table
34
8338012
Quill pin
82
8338047
Collar
35
NHH14
Half hex nut
83
C0408
Cheese head screw
Socket head M4x8
36
8338014
Power switch
37
CM05010
Countersunk screw M5x10
84
FW12
Washer M12
38
SZ1216
Set collar M12x16
85
55170
EMI filter
39
6919011
Basic sync
86
55106
Power cable
40
MPB0412
Main circuit board
87
FW17
Washer 17 mm
41
MPB0412
Flat head screw M4x12
88
LW17
Spindle locking washer
17 mm
42
MPB0325
Flat head screw M3x25
43
8338019
Cable bushing
M20 6-12 mm
89
LN17
Spindle locking nut
17 mm
44
8338020
Quick release mechanism
90
8339046
Rotor position disk
45
8339042
Mechanical depth stop rod
91
RW45
Spacer washer
rubber 45 mm
46
8339031
Mechanical depth stop
bracket
47
C05010
Cap screw M5
92
55020
Position sensor
