Teknatool Nova 83700 - User Manual

48 pages

Save Page as PDF

To Next Page

123-0420-029

OPERATION MANUAL

Viking DVR 16”

Drill Press

™

Publication: 123-0420-029

Date: 2 April 2020

Bench Models:

83700 – USA

83701 – NZ/Australia

83702 – Canada

83703 – Europe

83704 – UK

Floor Models:

83705 – Canada

83706 – USA

83707 – Europe

83708 – UK

83709 – NZ/Australia

Main Page

Questions and Answers

A
aaron65Jul 29, 2025
How to align the laser on a Teknatool Nova 83700?
- A
  Alexander HobbsJul 30, 2025
  To align the laser on your Teknatool Power Tool with the drill bit, follow these steps: 1. Secure a test workpiece onto the drill press table using a clamp or bolt. 2. Drill a small hole (approximately 3mm) into the workpiece. 3. Turn on the laser modules (avoid looking directly into the laser). 4. Loosen the grub screws on the side of the headstock. 5. Adjust the angle of the laser module until it intersects at the marked point. 6. Tighten the grub screws to lock the laser modules in place.
C
Colton BaileyAug 13, 2025
What to do if Teknatool Nova 83700 Power Tool attached tool does not run true?
- B
  Brendan CannonAug 13, 2025
  If the attached tool on your Teknatool Power Tool doesn't run true, the solution depends on where the runout is detected: * **Inside the drill press spindle:** Replace the entire spindle assembly. * **Morse Tapered tool/arbor:** Clean all contacting surfaces. If runout persists, try a different tool. * **Chuck:** Replace the chuck. * **Attached tool:** Ensure the tool is correctly mounted on the chuck. Always check from the spindle when identifying the cause of the runout.

Summary

Viking DVR 16 Drill Press Operation Manual

Contact Information

Safety Guidelines

General Safety Rules

Essential safety precautions for operating the drill press.

Additional Safety Rules for Drill Presses

Specific safety advice tailored for drill press operations.

Assembly Instructions

Power Connection and Workshop Setup

Connecting to Power

Guide on safely connecting the drill press to an electrical power source.

Workshop Environment Setup

Recommendations for lighting, electrical, and ventilation for the workspace.

Controls and Operation

Drill Press Interface Overview

Explanation of keypad buttons and display icons on the control panel.

Turning the Drill Press ON

Steps for powering on the drill press.

Basic Drill Press Functions

How to run, stop, use emergency stop, and adjust speed.

Depth Setting Functions

Advanced Functions and Settings

Electronic Depth Stop Functionality

Detailed use of the electronic depth stop system.

Quick Set Depth Function

Speed and Behaviour Settings

Maintenance and Performance Data

Drill Press Maintenance Schedule

Procedures for after-use, monthly, and semi-annual maintenance.

Speed Charts

Troubleshooting and Error Handling

Mechanical Issue Resolution

Diagnosing and fixing common mechanical problems.

Electrical Issue Resolution

Troubleshooting electrical faults and connection issues.

Understanding Error Codes

Interpreting and responding to HMI error messages.

Teknatool Nova 83700 Specifications

General

Motor Power	1.75 HP
Speed Range	100 - 5000 RPM
Swing Over Bed	14 inches
Distance Between Centers	37 inches
Spindle Thread	1 1/4" x 8 TPI RH
Tailstock Taper	MT2
Headstock Taper	MT2
Type	Wood Lathe
