Teknatool Nova 83700 - Power Spindle Hold Function

21
123-0420-029
The activation of the self-start function is indicated by
the self-start icon on the bottom of the HMI display
Note:
The self-starting depth is approximately 7mm from the top. This value is based on the absolute sensor readout
value therefore the threshold value will not be affected by any depth value offset made by the user.
The drill press will stop once the quill has been retracted back to 6mm depth.
Motor automatically starts with self start function
Motor automatically stops with self start function
Power Spindle Hold Function
Press and hold the <ON> button on for 3 seconds to
activate.
The drill press will apply power on the motor to lock
the spindle in position for 30 seconds.
Note:
This function is to allow easy hand tightening of a keyless chuck
7mm
Direction of quill
travel
6mm
Direction of quill
travel
Hold for 3
seconds
