Using the included accessories
Chuck Drift
The chuck drift is used to knock out the Morse Tapered tools that are attached into the drill press quill
Extend the drill press
spindle and turn the
quill by hand until the
side holes align
Insert the chuck drift
into the aligned hole
(Taper facing the
bottom)
Strike the chuck drift
from the end with a
mallet (or any tool
equivalent) to take
out the Morse
Tapered tool
Support the chuck
from the bottom
when striking the drift
