123-0420-029
SELF-START
Enables a one-handed drilling
operation by automatically turning on
and off.
SPLIT MOTOR
(EXPOSED)
Easy access to motor. Much easier to
get serviced for both customers and
dealers.
BRAKING
E-stop
Drill Press Specifications
Drill Press Physical Specifications
Swing
16” (406.4mm)
Stroke
4.5” (114.3mm)
Spindle to Table
12 2/3” (321.73mm)B / 30 2/5” (772.27mm)F
Spindle to Base
22 2/3” (575.73mm)B / 50 1/2" (1283.45mm)F
Drill Chuck
5/8” (1- 16mm)
Spindle Taper
2MT
Quill Diameter
60mm
Table Dimension
12 ½” x 12 ½” (320 x 320mm)
Base Dimension
18.45” (468.7mm) x 10.63” (270mm) x 2.17” (55mm)
Motor Specifications
Motor Type
DVR Direct Drive Smart Motor
Motor power output
1HP (0.75KW)
Maximum Speed
3,000 RPM (5,000 RPM when unlocked)
Minimum Speed
150 RPM
Input voltage
110V ~ 240V
Input Frequency
50/60 Hz
Input Current
15A (max) – For 115V input
10A (max) – For 240V input
