tekton 5409 - Vise Specifications and Parts; Part Reference Guide

Jaw width
Jaw opening
Throat depth
Swivel
Pipe jaw capacity
Weight
Anvil size
Mounting holes (3)
8 in.
6-3/8 in.
3-7/16 in.
360º
1-1/4 to 2-1/2 in.
40.2 lb.
3-3/4 in (square)
11/16 in. Ø
#5409 - 8in. Swivel Bench Vise
Sliding T handle
Anvil
Lockdown
Mounting hole
Jaw pad
Pipe jaw
Lead screw
Lead screw nut
PART REFERENCE GUIDE
VISE SPECIFICATIONS
Throat
