Tektronix AFG3000 Series Function Generator Guide v1.0 Portland State University
13
Example #3
For Channel 1, define a sine waveform with the following properties:
Frequency = 10 MHz, Amplitude = 2 V, Offset = 0.5 V, Phase = 0°.
For Channel 2, define a sine waveform with the following properties:
Period = 0.1 µs, High = 1.5 V, Low = -0.5 V, Phase = +45°.
In this example, the two signals are identical, except the Channel 2 waveform is shifted in phase with
respect to the Channel 1 waveform.
Setup for Channel 1
Buttons to push
Type
CH1/CH2
1
CB
Sine FB
Frequency/Period/Phase Menu BB
Frequency BB
10 NK
MHz BB
Phase
2
BB
0 NK
° BB
IB
Amplitude/Level Menu BB
Amplitude BB
2 NK
V
PP
BB
Offset BB
0.5 NK
V BB
1
If necessary, push the CH1/CH2 button
until Channel 1 is selected.
2
The default phase is 0°, so it really isn’t
necessary to set it explicitly in this case.
Setup for Channel 2
Buttons to push
Type
CH1/CH2
1
CB
Sine FB
Frequency/Period/Phase Menu BB
Period BB
0.1 NK
µ
s
BB
Phase BB
45 NK
° BB
IB
Amplitude/Level Menu BB
High Level BB
1.5 NK
V BB
Low Level BB
-0.5 NK
V BB
1
If necessary, push the CH1/CH2 button
until Channel 2 is selected.
