Troubleshooting
6-30 AFG3000 Series Arbitrary/Function Generators Service Manual
Error Codes
If Diagnostics detects a malfunction, it displays the character string “Fail” and the
error code. Table 6-4 describes the Error code and related modules Category of the
Diagnostics Error Code.
Table 6-4 shows the error code and related modules reporting a failure.
Table 6-4: Error codes
Error code Description Related module
--- Calibration ---
1101 CH1 Internal offset calibration failure A1x/A3x/A4x/A51/A61
1102 CH2 Internal offset calibration failure A12/A32/A42/A51/A61
1103 CH1 Output offset calibration failure A1x/A3x/A4x/A51/A61
1104 CH2 Output offset calibration failure A12/A32/A42/A51/A61
1105 CH1 Output gain Calibration failure A1x/A3x/A4x/A51/A61
1106 CH2 Output gain Calibration failure A12/A32/A42/A51/A61
1201 CH1 x3dB attenuator calibration failure A1x/A3x/A4x/A51/A61
1202 CH2 x3dB attenuator calibration failure A12/A32/A42/A51/A61
1203 CH1 x6dB attenuator calibration failure A1x/A3x/A4x/A51/A61
1204 CH2 x6dB attenuator calibration failure A12/A32/A42/A51/A61
1205 CH1 x10dB attenuator calibration failure A1x/A3x/A4x/A51/A61
1206 CH2 x10dB attenuator calibration failure A12/A32/A42/A51/A61
1207 CH1 x20dB 1 attenuator calibration failure A1x/A3x/A4x/A51/A61
1208 CH2 x20dB 1 attenuator calibration failure A12/A32/A42/A51/A61
1209 CH1 x20dB 2 attenuator calibration failure A1x/A3x/A4x/A51/A61
1210 CH2 x20dB 2 attenuator calibration failure A12/A32/A42/A51/A61
1211 CH1 Filter calibration failure A1x/A3x/A4x/A51/A61
1212 CH2 Filter calibration failure A12/A32/A42/A51/A61
1213 CH1 x20dB 3 attenuator calibration failure A43
1301 CH1 Sine Flatness calibration failure A1x/A3x/A4x/A51/A61
1302 CH2 Sine Flatness calibration failure A12/A32/A42/A51/A61
1401 CH1 ASIC TINT calibration failure A1x/A3x/A4x/A51/A61
1402 CH2 ASIC TINT calibration failure A12/A32/A42/A51/A61
1403 CH1 ASIC SGEN calibration failure A1x/A3x/A4x/A51/A61
1404 CH2 ASIC SGEN calibration failure A12/A32/A42/A51/A61
1405 CH1 ASIC clock duty calibration failure A1x/A3x/A4x/A51/A61
1406 CH2 ASIC clock duty calibration failure A12/A32/A42/A51/A61
