Tektronix AFG3252 Service Manual

Performance Verification
4-8 AFG3000 Series Arbitrary/Function Generators Service Manual
AC Flatness
AFG3011
CH1 AC Flatness
Frequency 100.00 kHz
(Ampl: +4.0 dBm)
---------- dB ( = Reference) ----------
Frequency 500.00 kHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 1.00 MHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 5.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
Frequency 10.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
AFG302xB
CH1 AC Flatness
Frequency 100.00 kHz
(Ampl: +4.0 dBm)
---------- dB ( = Reference) ----------
Frequency 500.00 kHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 1.00 MHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 5.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
Frequency 15.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
Frequency 25.00 MHz Reference – 0.50 dB dB Reference + 0.50 dB
CH2 AC Flatness
Frequency 100.00 kHz
(Ampl: +4.0 dBm)
---------- dB ( = Reference) ----------
Frequency 500.00 kHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 1.00 MHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 5.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
Frequency 15.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
Frequency 25.00 MHz Reference – 0.50 dB dB Reference + 0.50 dB
AFG3000 Series Performance Test Record
Minimum
Test result Maximum
