Tektronix AFG3252 Service Manual

Performance Verification
4-10 AFG3000 Series Arbitrary/Function Generators Service Manual
AC Flatness
CH2 AC Flatness
Frequency 100.00 kHz
(Ampl: +4.0 dBm)
---------- dB( = Reference) ----------
Frequency 1.00 MHz Reference – 0.15 dB dB Reference + 0.15 dB
Frequency 5.00 MHz Reference – 0.30 dB dB Reference + 0.30 dB
Frequency 25.00 MHz Reference – 0.50 dB dB Reference + 0.50 dB
Frequency 50.00 MHz Reference – 0.50 dB dB Reference + 0.50 dB
Frequency 100.0 MHz Reference – 1.00 dB dB Reference + 1.00 dB
Frequency 150.00 MHz Reference – 1.00 dB dB Reference + 1.00 dB
Frequency 250.0 MHz Reference – 2.00 dB dB Reference + 2.00 dB
AFG3000 Series Performance Test Record
Minimum
Test result Maximum
