Tektronix AFG3252 Service Manual

Performance Verification
AFG3000 Series Arbitrary/Function Generators Service Manual 4-25
6. (AFG3xx2 only) Repeat steps 3 through 5 for the channel 2 output.
AFG302xB and AFG310x Measurement Range
Function Offset
DC + 5.000 Vdc Vdc (5.000 × CF ± 0.055) Vdc
DC 0.000 Vdc Vdc ± 0.005 Vdc
DC – 5.000 Vdc Vdc (– 5.000 × CF ± 0.055) Vdc
AFG3251 and AFG3252 Measurement Range
Function Offset
DC + 2.500 Vdc Vdc (2.500 × CF ± 0.030) Vdc
DC 0.000 Vdc Vdc ± 0.005 Vdc
DC – 2.500 Vdc Vdc (– 2.500 × CF ± 0.030) Vdc
