Tektronix AFG3252

Specifications
Table 4: (Category) specifications (cont.)
Characteristic Description
PV reference
page
Resolution 1 μHz or 12 digits
Accuracy stability
±1 ppm, 0 °C to 50 °C (except Arb)
±1ppm±1mHz,0°Cto50°C(Arb)
(See page 51,
Frequency/period
test.)
Accuracy aging
±1 ppm/year
1
Triggered/Gated Burst mode:
AFG3011 / 3011C, 1 μHz to 5 MHz;
AFG3021B/3021C/3022B/3022C, 1 μHz to 12.5 MHz;
AFG3051C/3052C, 1 μHz to 25 MHz;
AFG3101/3101C/3102/3102C, 1 μHz to 50 MHz;
AFG3151C/3152C, 1 μHz to 75 MHz;
AFG3251/3251C/3252/3252C
,1μHz to 120 MHz
2
Triggered/Gated Burst mode:
AFG3011/3011C, 1mHz to2.5MHz;
AFG3021B/3021C/3022B/3022C, 1 mHz to 6.25 MHz;
AFG3051C/3052C, 1 MHz to 12.5 MHz;
AFG3101/3101C/3102/3102C, 1 mHz to 25 MHz;
AFG3151C/3152C, 1 mHz to 50 MHz;
AFG3251/AFG3252, 1 mHz to 60 MHz
Table 5: Phase (except DC, Noise, and Pulse)
Characteristics
Description
Range
1
–360° to +360°
1
Resolution: 0.01° (sine), 0.1° (other standard waveforms)
Table 6: Lead delay (pulse)
Characteristic Description
Range
Continuous mode
0 ps to period
Triggered/Gated Burst mode 0 ps to period – [pulse width + 0.8 * (leading edge time + trailing edge time)]
Resolution 10 ps or 8 digits
Table 7: Amplitude
Characteristic Description
PV reference
page
Range
1
,
3
AFG3011 / 3011C
20 mV
p-p
to 20 V
p-p
40 mV
p-p
to 40 V
p-p
(into open circuit load)
AFG3021B / 3021C / 3022B /
3022C / 3051C / 3052C
10 mV
p-p
to 10 V
p-p
20 mV
p-p
to 20 V
p-p
(into open circuit load)
AFG3101 / 3101C / 3102 /
3102C / 3151C / 3152C
20 mV
p-p
to 10 V
p-p
40 mV
p-p
to 20 V
p-p
(into open circuit load)
AFG3000C and AFG3000 Series Specifications and Performance Verification 9
