Performance veriﬁcation

Frequency, Amplitude, DC Offset, and AC Flatness Test Record (cont.)

AC Flatness (AFG310x / 310xC / 315xC)

CH1 AC Flatness

Minimum Test result Maximum

Frequency 1.00 k Hz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

Frequency 50.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

Frequency 100.0 MHz

Reference - 0.50 dB

Reference + 0.50 dB

AFG3151C / 3152C only

Frequency 150.0 MHz

Reference - 0.50 dB

Reference + 0.50 dB

CH2 AC Flatness

Minimum Test result Maximum

Frequency 1.00 k Hz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

Frequency 50.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

Frequency 100.0 MHz

Reference - 0.50 dB

Reference + 0.50 dB

AFG3151C / 3152C only

Frequency 150.0 MHz

Reference - 0.50 dB

Reference + 0.50 dB

AC Flatness (AFG325x / 325xC)

CH1 AC Flatness

Minimum Test result Maximum

Frequency 1.00 k Hz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

Frequency 50.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

Frequency 100.0 MHz

Reference - 1.00 dB

Reference + 1.00 dB

Frequency 150.00 MHz

Reference - 1.00 dB

Reference + 1.00 dB

Frequency 240.0 MHz

Reference - 2.00 dB

Reference + 2.00 dB

CH2 AC Flatness

Minimum Test result Maximum

Frequency 1.00 k Hz

(Ampl: +4.0 dBm)

———-

dB ( = Reference)

———-

Frequency 1.00 MHz

Reference - 0.15 dB

Reference + 0.15 dB

Frequency 5.00 MHz

Reference - 0.30 dB

Reference + 0.30 dB

Frequency 25.00 MHz

Reference - 0.50 dB

Reference + 0.50 dB

36 AFG3000C and AFG3000 Series Speciﬁcations and Performance Veriﬁcation
