Tektronix AFG3252 Technical Reference

Performance verification
AFG302xB / 302xC Measurement Range
Sine
+ 4.0 dBm
500.00 kHz
Reference ± 0.15
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 15.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.50
AFG305xC Measurement Range
Function Amplitude Frequency
(dBm)
(dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dBm
500.00 kHz
Reference ± 0.15
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 15.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 50.00 MHz
Reference ± 0.50
AFG310x / 310xC Measurement Range
Function Amplitude Frequency
(dBm)
(dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 50.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 100.00 MHz
Reference ± 0.50
AFG3151C / 3152C Measurement Range
Function Amplitude Frequency
(dBm)
(dB)
Sine
+ 4.0 dBm 1.00 kHz
= Reference
------
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
Sine
+ 4.0 dBm 5.00 MHz
Reference ± 0.30
Sine
+ 4.0 dBm 25.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 50.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 100.00 MHz
Reference ± 0.50
Sine
+ 4.0 dBm 150.00 MHz
Reference ± 0.50
AFG325x / 325xC Measurement Range
Function Amplitude Frequency
(dBm)
(dB)
Sine
+ 4.0 dBm 1.00 kHz
= R eference
------
Sine
+ 4.0 dBm 1.00 MHz
Reference ± 0.15
58 AFG3000C and AFG3000 Series Specifications and Performance Verification
