Tektronix AFG3252

Performance verification
AFG310x / 310xC Oscilloscope Measurement
Function Frequency
Offset
Amplitude Vertical Horizontal Limit
Square
10.00 MHz 0.0 V 1.0 Vpp
200 mV/div 2 ns/div
≤ 5ns
Square
10.00 MHz 0.0 V 10.0 Vpp
200 mV/div
with x10
attenuator
2ns/div
≤ 5ns
AFG3151C / 3
152C
Oscillosco
pe
Measuremen
t
Function Frequency
Offset
Amplitude Vertical Horizontal Limit
Square
10.00 MHz 0.0 V 1.0 Vpp
200 mV/div 2 ns/div
≤ 3.5 ns
Square
10.00 MHz 0.0 V 10.0 Vpp
200 mV/di
v
with x10
attenuator
2ns/div
≤ 3.5 ns
AFG325x / 325xC Oscilloscope Measurement
Function Frequency
Offset
Amplitude Vertical Horizontal Limit
Square
10.00 MHz 0.0 V 1.0 Vpp
200 mV/div 1 ns/div
≤ 2.5 ns
Square
10.00 MHz 0.0 V 5.0 Vpp
1.0V/div 1ns/div
≤ 2.5 ns
AFG3000C and AFG3000 Series Specifications and Performance Verification 69
