Tektronix AWG5204 Technical Reference

Specifications
Table 7: Signal output characteristics (cont.)
Characteristics Description
Amplitude range
Output path
DC High BW 25 mV
p-p
to 750 mV
p-p
into 50 Ω single-ended.
50 mV
p-p
to 1.5 V
p-p
into 100 Ω differential.
DC H igh BW
(with Option DC
Amplified)
25 mV
p-p
to 1.5 V
p-p
into 50 Ω single-ended.
50 mV
p-p
to 3.0 V
p-p
into 100 Ω differential.
DC High Volt
(Option HV)
10 mV
p-p
to5V
p-p
into 50 Ω single-ended.
20 mV
p-p
to 10.0 V
p-p
into 100 Ω differential.
AC Direct
–17 dBm to –5 dBm.
10 MHz to 3.5 GHz.
AC Amplified
(Option AC)
–85 dBm to 10 dBm (10 MHz to 3.5 GHz.)
–50 dBm to 10 dBm (3.5 GHz to 5 GHz.)
Amplitude accuracy and flatness degrades at frequencies beyond 3.5 GHz and below –50 dBm
output amplitude. It is not recommended to operate in this region.
Amplitude adjustment resolution
Output paths
DC High BW
1 mVpp or 0.1 dB.
DC High Volt
(Option HV)
1 mVpp or 0.1 dB.
AC Direct
0.1 dB
AC Amplified
(Option AC)
0.1 dB
DC amplitude accuracy
Within ±5 °C of internal self calibration temperature.
Output path
DC High BW Amplitude < 100 mV: ±5% of amplitude
Amplitude 100 mV to 1.5 V: ±2% of amplitude
DC High Volt
(Option HV)
Amplitude < 160 mV: ±5% of amplitude
Amplitude 160 mV to 5 V: ±2% of amplitude
AC amplitude accuracy
Output path
AC Direct 0.5 dB at 100 MHz (0 °C to 45 °C)
1 dB at 100 MHz (45 °C to 50 °C)
AC Amplified
(Option AC)
0.5dBat100MHz(0°Cto45°C)
1 dB at 100 MHz (45 °C to 50 °C)
AWG5200 Series Technical Reference 7
