Specifications
Table 7: Signal output characteristics (cont.)
Characteristics Description
DC Offset range
Output path
DCHighBW ±2Vinto50Ω to ground termination.
± 4 V into high resistance or matching voltage termination.
DC High Volt
(Option HV)
±2Vinto50Ω to ground termination.
± 4 V into high resistance or matching voltage termination.
DC Offset resolution
Output path (AC-path outputs use a different output bias circuit.)
DC High BW
1mV
DC High Volt
(Option HV)
1mV
DC Offset accuracy Differential offset is sensitive to output amplitude setting.
Within ±5 °C of internal self calibration temperature.
Common mode = ((OutP + OutN)/2).
Differential Mode = (OutP - OutN).
Output path
DC High BW
Com
mon mode
(Warranted)
±(2% of |offset| + 10 mV); into 50 Ω to ground termination.
Differential mode ±25 m V; into 100 Ω differential.
DC High Volt
(Option HV)
Common mode
(warranted)
±(2% of |offset| + 1% of amplitude + 20 mV).
Differential mode ± 88 mV; Into 100 Ω differential.
AC output DC bias range
Output path
AC Direct
± 5 V at 150 mA.
AC Amplified
(Option AC)
± 5 V at 150 mA.
AC DC bias resistance
Output path
AC Direct 1 Ω
AC Amplified
(Option AC)
1 Ω
8 AWG5200 Series Technical Reference
