Specifications
Table 7: Signal output characteristics (cont.)
Characteristics Description
AC DC bias acc
uracy
(warranted)
Output path
AC Direct ±(2% of bias + 20 mV); into an open circuit (zero load current).
AC Amplified
(Option AC)
±(2% of bias + 20 mV); into an open circuit (zero load current).
Analog bandwidth
Analog bandwidth is measured with the ideal sin(x)/x response curve of the DAC
mathemat
ically removed from the measured data.
Output p
ath
DC High
BW
At 750 mV
pp
single ended:
DC - 2 GH
z (–3 dB bandwidth).
DC - 4 GHz (–6 dB bandwidth).
DC H igh BW
(Option DC)
At 1.5 V
pp
single ended:
DC - 1.3 GHz (–3 dB bandwidth).
The analog bandwidth degrades as the amplitude is increased beyond 750 mV.
DC High Volt
(Opt
ion HV)
At 2 V
pp
single-ended:
DC – 370 MHz (–3 dB bandwidth).
At 4 V
pp
single-ended:
DC – 200 MHz (–3 dB bandwidth).
AC Direct 10 MHz - 2 GHz (–3 dB bandwidth).
10 MHz - 4 GHz (–6 dB bandwidth).
AC Amplified
(Op
tion AC)
10 MHz - 2 GHz (–3 dB bandwidth).
10
MHz - 4 GHz (–6 dB bandwidth).
Ri
se/fall time
Ri
se and fall times only apply to DC output paths.
O
utput path
D
CHighBW
< 115 ps at 750 mV
pp
single ended.
DC H igh BW
(Option DC)
< 180 ps at 1.5 V
pp
single ended.
DC High Volt
(Option HV)
<1.3ns,at5V
pp
single-ended.
<1.1ns,at4V
pp
single-ended.
<0.8ns,at3V
pp
single-ended.
<0.6ns,at2V
pp
single-ended.
Step response aberrations Step response aberrations only apply to D C output paths.
Output path
DC High BW < 16%
pp
, at 750 mV
pp
single ended.
DC H igh BW
(Option DC)
< 16%
pp
,at1.5V
pp
single ended.
DC High Volt
(Option HV)
< 10%
pp
,at5V
pp
single ended.
AWG5200 Series Technical Reference 9
