Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
AWG5202, AWG5204, AWG5208
Amplitude
25 mV
p-p
23.75 mV 26.25 mV
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch1–
1.5 V
p-p
1.47 V 1.53 V
Amplitude
25 mV
p-p
23.75 mV 26.25 mV
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch2–
1.5 V
p-p
1.47 V 1.53 V
AWG5204, AWG5208
Amplitude
25 mV
p-p
23.75
mV
26.25
mV
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 m
V
p-p
480 m
V
520 m
V
1V
p-p
980 mV 1.02 V
Ch3–
1.5 V
p-p
1.47 V 1.53 V
Amp
litude
25 mV
p-p
23.75 mV 26.25 mV
100 mV
p-p
98 mV 102 mV
20
0mV
p-p
19
6mV
20
4mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch4–
1
.5 V
p-p
1
.47 V
1
.53 V
A
WG5208
Amplitude
25 mV
p-p
23.75 mV 26.25 mV
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch5–
1.5 V
p-p
1.47 V 1.53 V
66 AWG5200 Series Technical Reference
