Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
Amplitude
25 mV
p-p
23.75 mV 26.25 mV
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch6–
1.5 V
p-p
1.47 V 1.53 V
Amplitude
25 mV
p-p
23.75 mV 26.25 mV
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch 7–
1.5 V
p-p
1.47 V 1.53 V
Amplitude
25 mV
p-p
23.75 m
V
26.25 m
V
100 mV
p-p
98 mV 102 mV
200 mV
p-p
196 mV 204 mV
500 mV
p-p
480 mV 520 mV
1V
p-p
980 mV 1.02 V
Ch8–
1.5 V
p-p
1.47 V 1.53 V
AWG5200 Series Technical Reference 67
