Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
AWG5202, AWG5204, AWG5208
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch1–
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch2–
–5 V –5.12 V –4.88 V
AWG5204, AWG5208
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch3–
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch4–
–5 V –5.12 V –4.88 V
AWG5208
DC Bias
5V 4.8
8V
5.1
2V
0 V –20 mV 20 mV
Ch5–
–5 V –5.12 V –4.88 V
DC Bias
5
V
4
.88 V
5
.12 V
0 V –20 mV 20 mV
Ch6–
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch7–
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch8–
–5 V –5.12 V –4.88 V
78 AWG5200 Series Technical Reference
