Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
Marker
High Level Accuracy
AWG5202, AWG5204, AWG5208
CH1:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH1:2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH1:3
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH1:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH2:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3
V
–0.3
05 V
–0.2
95 V
CH2:
2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH2:3
+1.
75 V
1.5
5V
1.9
5V
0.
0V
–2
5mV
+2
5mV
–0.3 V –0.305 V –0.295 V
CH2:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–
0.3 V
–
0.305 V
–
0.295 V
AWG5200 Series Technical Reference 79
