Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
AWG5204, AWG5208
CH3:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH3:2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH3:3
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH3:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH4:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.30
5V
–0.29
5V
CH4:
2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH4:3
+1.
75 V
1.5
5V
1.9
5V
0.0
V
–25
mV
+25
mV
–0.3 V –0.305 V –0.295 V
CH4:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–
0.3 V
–
0.305 V
–
0.295 V
A
WG5208
CH5:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH5:2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH5:3
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH5:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
80 AWG5200 Series Technical Reference
