Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
CH6:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH6:2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH6:3
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH6:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH7:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305
V
–0.295
V
CH7:2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH7:3
+1.7
5V
1.55
V
1.95
V
0.0
V
–25
mV
+25
mV
–0.3 V –0.305 V –0.295 V
CH7:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0
.3 V
–0
.305 V
–0
.295 V
C
H8:1
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH8:2
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH8:3
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV +25 mV
–0.3 V –0.305 V –0.295 V
CH8:4
+ 1.75 V 1.55 V 1.95 V
0.0 V –25 mV 25 mV
–0.3 V –0.305 V –0.295 V
AWG5200 Series Technical Reference 81
