Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
Marker
Low Level Accuracy
AWG5202, AWG5204, AWG5208
CH1:1
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH1:2
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH1:3
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH1:4
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH2:1
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500
mV
–0.5
25 V
–0.4
75 V
CH2:
2
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH2:3
+1.
55 V
1.3
7V
1.7
3V
0.
0V
–2
5mV
25
mV
–500 mV –0.525 V –0.475 V
CH2:4
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–
500 mV
–
0.525 V
–
0.475 V
82 AWG5200 Series Technical Reference
