Tektronix DPO4034 Technical Reference

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
RMS Noise
Model Bandwidth selection 1 MΩ 50 Ω
Full Bandwidth
≤(133 µV + 7.3% of
Volts/div Setting)
≤(72.3 μV + 6% of
Volts/div Setting)
250 MHz
≤(99.5 µV + 5.0% of
Volts/div Setting)
≤(49.6 µV + 3.7% of
Volts/div Setting)
DPO4104
20 MHz
≤(20.8 µV + 3.3% of
Volts/div Setting)
≤(12.8 µV + 3.3% of
Volts/div Setting)
Full Bandwidth
≤(130 µV + 7.6% of
Volts/div Setting)
≤(77.9 μV + 3.1% of
Volts/div Setting)
250 MHz
≤(96.2 µV + 5.2% of
Volts/div Setting)
≤(56.7 µV + 3.3% of
Volts/div Setting)
DPO4054
20 MHz
≤(22.7 µV + 3.8% of
Volts/div Setting)
≤(13.6 µV + 3.3% of
Volts/div Setting)
Full Bandwidth
≤(139 µV + 6.4% of
Volts/div Setting)
≤(77.7 µV + 3.3% of
Volts/div Setting)
250 MHz
≤(94.0 µV + 4.8% of
Volts/div Setting)
≤(76.6 µV + 3.2% of
Volts/div Setting)
DPO4034
20 MHz
≤(22.3 µV + 3.4% of
Volts/div Setting)
≤(16.0 µV + 3.1% of
Volts/div Setting)
Full Bandwidth
≤(141 µV + 7.2% of
Volts/div Setting)
≤(81.6 µV + 3.1% of
Volts/div Setting)
250 MHz
≤(87.9 µV + 4.9% of
Volts/div Setting)
≤(73.8 µV + 3.9% of
Volts/div Setting)
Random Noise
,
Sample Acquisition
Mode
DPO4032
20 MHz
≤(18.5 µV + 3.1% of
Volts/div Setting)
≤(12.7 µV + 3.6% of
Volts/div Setting)
Aperture uncertainty
≤(3 ps + 0.1 ppm × Record D uration)
RMS
, for records having duration ≤1 minute
MSO4000 and DPO4000 Series Specifications and Performance Verification 5
