Giving Demos of MSO Features
Now let’s create a clocked bus.
8. Push Define Inputs from the lower-bez el
menu.
Bus B1
Parallel
Define
Inputs
Thresholds B1 Label Bus Display Event Table
96 Demo 2 Board Instruction Manual
