Learn how to troubleshoot a serial bus.
Bus selection list
From the Bus Setup window, select a bus to set up from the list of Bus selections <B1-B16>.
To use
■
Click and drag the scroll bar until the desired Bus number or name is visible.
■
Click the Bus number <B1–B16> or name to be set up.
Behavior
Click the Bus button to display the bus (On) or to remove it from the display (Off).
What do you want to do next?
Learn more about bus setups.
Learn about bus configuration.
Learn about digital setups.
Bus setups
