To use. For information on the controls, click the buttons.

■

Trigger Type

■

Mark All Trigger Events

■

Settings

■

Source

■

Data Level

■

Clock Source

■

Clock Level

■

Setup / Hold Time

■

Clock Edge

■

Qualification

■

Pattern

■

Edit Button

NOTE. The Trigger Setup/Hold screen on DPO and MSO instruments is the same except for the source selection and Trigger if

Setup/Hold Qualification options. In some instruments, the source selection is a drop-down list and the Trigger if Setup/Hold

Qualification option has Occurs and Logic. In other instruments the source selection includes a combo list and a Select button.

The Trigger if Setup/Hold Qualification option has Occurs, Logic, and Occurs And.

The following Trigger Setup/Hold screen appears on MSO70000C/DX and DPO7000C Series instruments:

The following Trigger Setup/Hold screen appears on MSO/DPO5000B Series instruments:

Trigger setups

DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 425
